3 axis robot arm
lisa Lee
Contact person
Basic Information
| Place of Origin | Jiangsu China (Mainland) |
|---|---|
| Brand Name | Mingseal |
| Model Number | DX-210 |
1..X.Y.Z axes work together,can meet the need of 3D space complicated graphics glue-dispensing 2.Combine with assembly line conveyor belt,can fulfill automatic production line work; 3.Specially suit to the big size and inconvenient moving workpieces' glue dispensing . 4.X,Y axis can adopt stepper motor or servo-actuator controlling according customer's requirment,Z axis adopt precision stepper motor controlling; 5.Cantilever structure,can fix types of fixtures on the platform;also can meet different customers' requirment and develop types of fixtures which fix on the Z axis. Specification ItemDX-210Work AreaX200mmY100mmZ80mmMax SpeedX300mm/sY300mm/sZ300mm/sRepeated Location Accuracy±0.02mmMax LoadingZ axis: 2.5Kg(running speed<60mm/s)Size(length,width,height)610mm*330mm*590mmWeight28KgStored Assignment120pcsExternal CommunicationsRS232Power220V ±10% 50Hz±10%Temperature0 40°CRelative Humidity20% 90%(without dewdrop)
-
