DM-100 Mini-microphone automatic assembly line

Description DM-100 Mini-microphone automatic assembly line integrates the microphone's assemblying,edge folding,anaplastic,detection,and classification; there are four modules:1.automatic assemblying module of shell,diaphragm and gasket; 2.manual assemblying module of back plate,plate adapter and PCB; 3.automatic folding and anaplasty module; 4.detection and classification module. This equipment can accomplish mini-microphone's key production processing automatically. Specification productivity40000pcs/8hproducing modeuploading,assemblying,edge folding,anaplasty,detection and classification all automaticallycontrolling systemmodule embedded type controlling systemoperating modetouch screenlocation modeservocontrol integrates with air operated controller and stepping motorrepeated location accuracy±0.02mmdetection accuracy0.001mmclassification10 grades,can be classified as high-class,qualified and reject;Power supply220V±10% 50Hz±10%air pressure0.5Mpa 0.7Mpamax consume air pressure300NL/minpower4.8KWsize(length,width,height)8300*3800*2000Temperature0 40°CRelative Humidity:20% 90%(without dewdrop)
